Introduction
This HDMI 4K Splitter use a single HDMI source, accessing to multiple HDMI sinks, it allows one HDMI device to be split easily to 4/8/16 compatible monitors or projectors or video wall, it can also be placed at the end of a long HDMI cable to regenerate the HDMI signal, the resolution of this HDMI splitter can be up to 3840X2160/30hz.
Features
- Support HDMI 1.4b version
- Support 3D video format
- Support high resolution up to 3840×2160/30Hz
- Support Highest rate of 3.4G and TMD clock can be up to 340Mhz
- Support 8/10/12 bit deep color
- Support AWG26 HDMI standard cable: input up to 20 meters, output up to 20 meters.(when the resolution is 4K, input up to 15 meters, output up to 15 meters.)
- Support one signle HDMI source, accessing to multiple HDMI sinks, the source can be DVD player, A/V receiver, set top box and etc.
- 5V/1A power adapter
Connection Diagram
Connection Operation
- connect the HD source to the splitter input with one HDMI cable
- connect the splitter output to the displays with 4 hdmi cables
- connect 5V/1A power adapter to the splitter
Application scene
Shopping mall
TV store
Teaching
